BINSFELD ENGINEERING INC.

TorqueTrak 10K

TorqueTrak 10K

TEMPORARY TEST MEASUREMENT

Measuring live torque in real time is easier than ever with the new TorqueTrak 10K telemetry system. Convert virtually any drive shaft into a rotating torque sensor by simply mounting the transmitter, battery and a torque sensitive strain gage to the shaft.

Use the infrared remote control to adjust transmitter gain, activate the remote shunt calibration or switch the transmitter to standby power mode. The multi-line LCD receiver display and keypad make system adjustments straightforward. Low power consumption in the rugged transmitter allows longer battery life while sophisticated electronics assure accurate and reliable torque data output.

Features & Benefits

Easy to Use - Fits any size shaft, any torque level. No machine modifications or disassembly required. Calibration is done off-the-shaft. Receiver display and keypad offer user-friendly interface.

Infrared Remote Control - Control transmitter operation including channel select, gain/range, shunt calibration and low-power standby mode.


Reliable Data Transmission - Clean, noise-free data signal through analog voltage output or digital data output via RS-232.

Standby Power Mode - Extends transmitter battery life without disconnecting battery.

16 Channels, - 500 Hz Frequency Response Use multiple systems simultaneously.

Rugged - Reinforced, injection-molded transmitter housing is built for demanding applications and features V-groove and tape slot for secure mounting.

User Adjustable Gain - Amplify the strain/torque signal to the most useful level.


Specifications

Click here for full product specifications.

Click here pdf for Product Datasheet.

Warranty Information

Binsfeld Engineering Inc. warrants that its TorqueTrak 10K products will be free from defective material and workmanship for a period of one year from the date of delivery to the original purchaser and that its products will conform to specifications and standards published by Binsfeld Engineering Inc.  Upon evaluation by Binsfeld Engineering Inc., any product found to be defective will be replaced or repaired at the sole discretion of Binsfeld Engineering Inc.  Our warranty is limited to the foregoing, and does not apply to fuses, paint, or any equipment, which in Binsfeld Engineering’s sole opinion has been subject to misuse, alteration, or abnormal conditions of operation or handling.

More Info

General technical information can be found on the Common Topics page.

Click here to request more info, or feel free to contact us toll-free at 1-800-524-3327.

Optional Op-Torq Field Test 2

Op-Torq FIELD TEST 2, User's Manual pdf

The Op-Torq FIELD TEST 2 data acquisition system typically will be used with the TorqueTrak 10K telemetry instrument for temporary installation and short-term test measurements.  The Op-Torq FIELD TEST 2 system can also be used with the permanently installed TorqueTrak Revolution instrument.  The program is preconfigured for Torque, RPM and Power data processing on one, two, three or four shafts.  The Op-Torq FIELD TEST 2 system is powerful, yet easy to use.  Use Timed Acquisition mode for data analysis over time.  Use High Frequency mode for torsional vibration analysis.  Log, analyze, graph and export the data.  Create reports.  Options include integration of up to four additional analog data signals – pressure, temperature, humidity or anemometer, for example.  An Electrical Power Meter signal can be integrated.  And for moving vehicles such as trucks and ships, GPS data can be integrated so that vehicle Speed and Distance can be correlated to engine Power consumed.

Notes:

a.  Op-Torq FIELD TEST 2 primarily consists of data acquisition software and the Acquisition Module.  The system does not include a computer.  However, by special request, we can supply a laptop computer preconfigured with the data acquisition software.

b.  Op-Torq FIELD TEST 2 program is powered by LabVIEW.

c.  Windows XP or Windows 7 operating system is recommended to ensure the highest level of performance with the Op-Torq FIELD TEST 2 software.  For use with Windows Vista, the Windows Vista Business version or Ultimate version is required.

Pricing

Please register to view our price list.
